QUALITY CHARACTERISTICS
·
·
meets the requirements for 120 minutes at room connec-
tions and thermal insulation (F120 and EI 120)
·
·
fire resistance period of F30, F120, EI 30 and EI 120
certified by iBMB MPA Braunschweig
·
·
tested by iBMB MPA Braunschweig ABP P-3436/5813 −
MPA BS and PB 2400/157/15 − Rue
·
·
permanently elastic, with a high long term movement
capacity
·
·
for joint dimensions from 4mm up to 40mm
·
·
sound and thermal insulating
·
·
halogen, fibre and solvent-free
·
·
can be covered with silicones
QUALITY CHARACTERISTICS
·
·
meets the requirements of DIN 4102 part 9 for
fire resistance classes S30, S60 and S90
·
·
quick and clean application without special tools
·
·
no preparation of the wall or ceiling opening
·
·
easy fitting of cables (soft foam fire barrier)
·
·
no cracking due to permanent elasticity with high capacity
to absorb constant movements
·
·
totally free from dust and fibres, impermeable to flue
gases
·
·
flexible application (temporary / permanent fire protection)
·
·
free from halogens and solvents
OUR SYSTEM PRODUCTS
FOR FIRE PROTECTION
ISO-FLAME KOMBI F 120
FIRE STOP FOR MOVEMENT JOINTS
ISO-FLAME BRICK S 90
CABLE / PIPE FIRE STOP
ISO-FLAME BRICK S90 is a fire resistant, impregnated PUR
high resilient foam form used as a fire-protection of single
cables, cable bundles and pipes (service fire stops). It is used
in rectangular and irregular openings in fire walls and ceilings
and in accordance to DIN 4102 part 9 for F classes S30,
S60 and S90. Its maximum fire resistance durability is 90
minutes. ISO-FLAME BRICK S90 is totally free from fibres and
dust, making it particularly suitable for use in dirt sensitive
rooms. ISO-FLAME BRICK S90 can be installed quickly and
cleanly without the need for special tools. The fitting of single
cables. cable bundles, pipes and cable looms is simply done
by cutting.
ISO-FLAME KOMBI F120 is a PUR-sealing tape impregnated
with a special highly flame resistant impregnation which
withstands fire and smoke for at least 30 or 120 minutes in
the event of a fire. It therefore fulfils the most stringent fire
protection requirements, making it excellent as a fire-stop for
expansion and movement joints in components used to create
fire zones. No pre-treatment of the joint or additional sealing
with kitt at the joint faces is needed. The tape may be covered
with standard silicone compounds so that it fulfils other re-
quirements in terms of visual appearance and watertightness.
ISO-FLAME KOMBI F120 can be used in all areas of con-
struction and building types.
