QUALITY CHARACTERISTICS
·
·
meets the requirements of DIN 4102 part 9 for
fire resistance classes S30, S60 and S90
·
·
quick and clean application without special tools
·
·
no preparation of the wall or ceiling opening
·
·
easy fitting of cables (soft foam fire barrier)
·
·
no cracking due to permanent elasticity with high capacity
to absorb constant movements
·
·
totally free from dust and fibres, impermeable to flue
gases
·
·
flexible application (temporary / permanent fire protection)
·
·
free from halogens and solvents
ISO-FLAME PLUG S 90
CABLE / PIPE FIRE STOP
ISO-FLAME PLUG S90 increases building safety in the vici-
nity of fire walls and ceilings. It also acts as a fire protection
for single cables and cable bundles on circular openings in
concrete, reinforced concrete, cellular concrete, brick-work
or lighter partitioning walls. The ready to use foam form is
made from fire resistant, impregnated PUR foam and is ap-
proved for fire resistance classes S30, S60 and S90. Being
totally free from fibres and dust it i s particularly suitable for
use in dirt sensitive rooms. ISO-FLAME BRICK S90 can be
installed quickly and cleanly without the need for special tools
and the foam is simply cut to accommodate the various
cables.
ACCESSORIES
ISO-FLAME KITT & ISO-FLAME SET
ISO-FLAME KITT is an ablative, trowel-on white
fire protection compound (ABZ Z-19.11-1571).
The cut surfaces of the foam form should be
coated with ISO-FLAME KITT when ISO-FLAME
PLUG S 90 and BRICK S 90 are used. In the case
of ceiling openings, both visible fire stop surfaces
should be sealed using ISO-FLAME KITT.
ISO-FLAME SET consists of a building authority ap-
proval (ABZ) with certificate of conformity or manu-
facturer’s certificate, plus an implementation notice.
